Description
- Specifications
- User Manual
- Product Review Video
- Data Sheet
- Certificate of Conformity
| DSP & Sensor | 2441H+SONY323 |
| Image Sensor | 1/3" Sony 2.0MP CMOS Sensor |
| Image Resolution | 1920*1080 |
| Effective Pixels | 2MP |
| TV System | PAL/NTSC |
| Electronic Shutter | 1/10s~1/100,000s |
| S/N Ratio | ≥50dB |
| Scanning System | Progressive Scan |
| Focus Length | Board Lens 3.6mm/F2.0 |
| Focus Control | Fixed |
| Lens Type | Fixed |
| Megapixels | 2M Pixel |
| Auto Iris Support | N/A |
| Infrared SMD LED | 35 PCS |
| Infrared Distance | 25-30M |
| IR Status | Under 10 Lux by CDS |
| IR Power On | CDS Auto Control |
| Day & Night | Auto (ICR) / Color / B&W |
| OSD Menu Language | NO |
| White Balance | Auto |
| Gain Control | Auto |
| Noise Reduction | 2D NR |
| Picture Adjustment | N/A |
| WDR | YES |
| OSD Support | NO |
| UTC | N/A |
| Housing | Plastic |
| Bracket | NO |
| Dual Voltage | N/A |
| IR Cut Filter | YES |
| Heater | N/A |
| Operation Temperature | -10℃ ~ +50℃ RH95% Max |
| Storage Temperature | -20℃ ~ +60℃ RH95% Max |
| Power Source | DC12V±10%, 230mA |
| Title | Language | Download |
| Ahd Camera | English, Turkish | Click Here |
