| Case | Metal-Bullet |
| Sensor | 1/2.8” IMX335 |
| DSP | FH8538M |
| System | PAL/NTSC |
| Effective Pixel | 2560(H)x1920(V) 5mp 4:3 |
| 2560(H)x1440(V) 4mp 16:9 | |
| Illumination | 0.01Lux@(F1.2,AGC ON),0LUX with IR |
| Shutter | AUTO |
| D/N | EXT(Default)/COLOR/B/W |
| Synchronously | Internal |
| FPS | 5MP@20fps/12.5fps / 4MP@25fps/30fps/15fps |
| Video output | AHD/TVI/CVI can be switch |
| Exposure | Shutter/AGC/Brightness |
| AWB | ATW/MWB |
| DAY-NIGHT | INFRARED/COLOR/B&W |
| Video Setting | Contrast/Sharpness/Color Gain/DNR |
| Video Output | AHD:5MP20/12.5/4MP25/30/15,CVBS:PAL/NTSC |
| TVI:5MP20/12.5/4MP25/30/15,CVI:4MP25/30 | |
| Language | Chinese/English |
| Operation Temperature | -20℃ to 60℃ |
| Working Humidity | Relative humidity less than90 % |
| Power | DC12V(±20%) - 70MA |
| Size | 32*32/38*38(mm) |
| Title | Language | Download |
| Ahd Camera | English, Turkish | Click Here |
