| Case | Metal-Bullet |
| Sensor | 1/2.5＂JX-K03 |
| System | PAL/NTSC |
| Effective pixels | 2704(H)x1950(V) |
| Illumination | 0.1Lux@(F1.2,AGC ON)，0LUX with IR |
| Shutter | AUTO |
| D/N | EXT（Default）/COLOR/B/W |
| Synchronously | Internal |
| FPS | 5.0MP@20fps / 5.0MP@15fps |
| Video output | AHD/TVI/CVI/CVBS switch |
| Exposure | BRIGHTNESS / EXPOSURE MODE / GAIN |
| BW | ATW/MWB |
| D/N MODE | Infrared/COLOR/B&W |
| Video Setting | Contrast/Sharpness/COLOR GAIN/DNR |
| Language | CHINESE/ENGLISH |
| Operation Temperature | -20℃ to 60℃ |
| Operation humidity | Relative humidity less than 90 % |
| Power | DC12V(±20%) - 70MA |
| Dimension | 32*32/38*38（mm） |
| Title | Language | Download |
| Ahd Camera | English, Turkish | Click Here |
