| Video Input | 4 Channel |
| Network Video Bandwidth | 20M |
| HDMI/VGA | 1 Channel 1280*1024/ 1280×800/1024*768 |
| Audio Output | 1 Channel, RCA Port |
| Record Resolution | 1920×1080/ 1280×960/1280×720 /768×432/704×576 |
| Video Encoding Resolution | 4ch 1080P/960P/720P |
| Synchronous Playback | 1ch 1280*1024 /1280×800/1024*768 |
| Record Type | Manual, Scheduled, Alarm triggered, Motion Detection triggered |
| Playback Mode | Time List&Event Playback |
| Backup Mode | Video Backup&Picture Backup |
| HDD Type | SATA Port |
| Quantity of HDD | 1 PCs (supports up to 4TB HDD) |
| Two-way talk | 1 Channel, RCA Port |
| Network Port | 1 RJ-45, 10M/100M Ethernet Self-adaption |
| PTZ Port | RS485 |
| USB Port | 2 USB2.0 |
| Alarm Input | 4 Group, Total 32 Channels, Alarm Box Input |
| Alarm Output | 4 Group, Total 32 Channels, Alarm Box Input |
| Protocol | TCP/IP, DHCP, UDP, SMTP, NTP, CloudSEE |
| Work Temperature | -10℃～+55℃ |
| Work Humidity | 10%～90% |
| Power | DC12V |
| Watts | ≤15W(without HDD) |
| Language | Chinese / English / Russian / German / French / Italian / Dutch / Korean / Japanese / Thai / Vietnamese / Indonesian / Polish / Spanish / Portuguese / Turkish |
| Chassis | Standard 1U chassis |
| Size(W*H*D)(mm) | 295*45*235 |
| Weight (g) | ≦1200(Without HDD) |
